Inverter; Pn:1,5-2,2kW;3×380-480V;In max:5,5A;(1,5kW;4A);PROFINET;IP20
| SERIES | FR-E800 SERIES |
|---|---|
| TYPE | FR-E800-ETH INVERTER |
| MINIMUM RATED VOLTAGE (V) | 380 |
| MIN. PERMISSIBLE VOLTAGE (V) | 323 |
| MAXIMUM RATED VOLTAGE (V) | 480 |
| MAX. PERMISSIBLE VOLTAGE (V) | 528 |
| CURRENT TYPE | AC |
| PHASES | 3 |
| RATED OUTPUT CURRENT LD (A) | 5,5 |
| RATED OUTPUT CURRENT ND (A) | 4 |
| RATED MOTOR CAPACITY LD (KW) | 2,2 |
| RATED MOTOR CAPACITY ND (KW) | 1,5 |
| CONTROL METHOD | V/F CONTROL REAL SENSORLESS VECTOR CONTROL PM SENSORLESS VECTOR CONTROL MAGNETIC FLUX VECTOR CONTROL |
| MOTOR TYPE | INDUCTION MOTOR, PM MOTOR |
| BRAKE CHOPPER ED (%) | 100 |
| INTEGRATED EMC FILTER | NO |
| SAFE TORQUE OFF (STO) | YES |
| REGENERATIVE (4Q) | NO |
| INTEGRATED DC CHOKE | NO |
| DISPLAY | BUILT-IN |
| DISPLAY TYPE | 4 DIGITS LED |
| PLC FUNCTION | YES |
| PROGRAM MEMORY | 2K |
| PROGRAM MEMORY UNIT | STEPS |
| INTEGRATED DIGITAL INPUTS | 2 |
| DIGITAL OUTPUTS (TRANSISTOR) | 0 |
| DIGITAL OUTPUTS (RELAY) | 1 |
| INTEGRATED ANALOGUE INPUTS | 2 |
| INTEGRATED ANALOGUE OUTPUTS | 0 |
| IO TYPE OF TERMINAL BLOCK | SPRING CLAMP |
| EXPANDABLE | YES |
| RS-485 | NO |
| USB | 1 (MINI B) |
| ETHERNET PORT | 2 |
| BUILT-IN NETWORK | CC-LINK IE TSN MODBUS/TCP PROFINET CC-LINK IE FIELD BASIC |
| LEAKAGE CURRENT (MA) | 1,2 |
| POWER LOSS LD (W) | 85 |
| POWER LOSS ND (W) | 59 |
| STANDBY POWER CONSUMPTION (W) | – |
| PROTECTION CLASS | IP20 |
| FREQUENCY RANGE (HZ) | 0,2–590 |
| WIDTH (MM) | 108 |
|---|---|
| HEIGHT (MM) | 128 |
| DEPTH (MM) | 135 |
| WEIGHT (KG) | 1,4 |
